Power Amplifiers (DC Powered)

DBPA4846005300A

90W U-Band Solid State Power Amplifier 46GHz-53GHz，90W

• Features
• Frequency Range 46-53GHz
• Gain 56dB
• Psat 49.5dBm
• Intelligent Protection

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA5300020100A

0.03-1GHz,200W

• Features
• Frequency Range: 0.03-1GHz
• Small Signal Gain：55dB
• Saturated Output Power：53dBm
• Gain Variation Over Temperature：±2dB

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA5418002650A

K-band Power Amplifier 18-26.5GHz,200W

• Features
• Frequency Range: 18-26.5GHz
• Small Signal Gain：60dB
• Saturated Output Power：53dBm
• Gain Variation Over Temperature：±3dB
• Supports Liquid Cooling

RFQ

Datasheet

PIN Switches

DBSA0202000400F

PIN Switch 2-4GHz/SP2T

• Features
• Frequency Range: 2-4GHz
• Insertion Loss：1dB
• Isolation：85dB
• Switching Speed：100ns

RFQ

Datasheet

Low Noise Amplifiers (DC Powered)

DBLNA306001800J

Low Noise Driver Amplifier 6-18GHz，+28 dBm

• Features
• Operating Voltage +15V
• RF Input Power (RFIN) -3dBm
• Operational Temperature -40°C~+85°C
• Storage Temperature -50°C~+105°C
• Altitude 30,000 ft. (Epoxy Sealed Controlled environment)
• 60,000 ft. 1.0psi min (Hermetically Sealed Un-controlled environment)
• (Optional)
• Vibration 25g RMS (15 degrees 2KHz)
• endurance, 1 hour per axis
• Humidity 100% RH at 35°C, 95%RH at 40°c
• Shock 20G for 11msec half sine wave,3
• axis both directions

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA4826504000A

Power Amplifier 26.5-40GHz，79.5W

• Features
• Frequency Range 26.5-40GHz
• Gain: 55dB Typical
• Saturated Output Power 49dBm Typical
• Gain Variation Over Temperature ±3dB

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA5226004000A

Solid State Power Amplifier With Air Cooling 26.5-40GHz

• Features
• Frequency Range 26.5-40GHz
• Small Signal Gain 60dB Typical
• Output Saturation Power 52dBm Typical
• Power Added Efficiency (PAE) 10%

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA4533003700A

Wide Band Power Amplifier 33-37GHz，31.5W

• Features
• Frequency Range 33-37GHz
• Gain: 55dB Typical
• P1dB Output Power 42dBm Typical
• Saturated Output Power 45dBm Typical

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA4646005300A

Power Amplifier 46-53GHz，45W

• Features
• Frequency Range 46-53GHz
• Small Signal Gain 52dB
• Output Saturation Power 46.5dBm
• Output 1dB Compression Point 43dBm

RFQ

Datasheet

Electromechanical Switches

DBMT0600005000A

Electromechanical Switch DC-50GHz，SP6T

• Features
• Frequency Range:DC-50GHz
• Insertion Loss:1.2dB Max
• Voltage:12V
• Isolation: 50dB Min

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA4501000800A

Solid State Power Amplifier 1-8GHz，40W

• Features
• Frequency Range:1-8GHz
• Gain:54dB Typical
• Psat:42dBm Typical
• P1dB:43dBm Typical

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA5018004000A

Solid State Power Amplifier 18-40GHz，100W

• Features
• Frequency Range:18-40GHz
• Gain:65dB Typical
• Psat:50dBm Typical
• P1dB:46dBm Typical

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA5308001200A

200W Wide Band Solid State Power Amplifier 8~12GHz

• Features
• Frequency Range:8~12GHz
• Gain:63dB Typical
• Psat:53dBm Typical
• P1dB:47dBm Typical

RFQ

Datasheet

USB/LAN Control Attenuators

DBDA0600104000U

USB/LAN Control Attenuators 0.1–43.5GHz

• Features
• Frequency Range: 0.1-43.5GHz
• Attenuation Range: 63dB
• Control Step Size 1dB
• USB Controlled and Powered

RFQ

Datasheet

Power Amplifiers (AC Powered)

DBACPA18004000B

Wide Band Solid State Power Amplifier AC 110V/220V 18GHz~40GHz

• Features
• Frequency Range: 18-40GHz
• Gain: 49dB
• Output power 42dBm
• High P1dB: 39 dBm

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA3740006000A

40-60GHz Wide Band Power Amplifier

• Features
• Frequency Range: 40-60GHz
• Gain: 45dB
• Output power +37dBm
• High P1dB: +33 dBm Full Band

RFQ

Datasheet

Digital Phase Shifters

DBDP0618002600B

Digital Non-Dispersive 360º Phase Shifter 18-26GHz

• Features
• Frequency Range: 18-26GHz
• Phase Range: 360°
• Control Bits: 6bit
• Control Step size: 5.625°
• Phase Flatness: ±5°

RFQ

Datasheet

PIN Switches

DBDS0400504350A

0.5-43.5GHz DPDT Switch

• Features
• Frequency Range: 0.5-43.5GHz
• Insertion Loss: 5dB Max
• Isolation: 70dB
• Switching Speed: 100 ns

RFQ

Datasheet

Power Amplifiers (DC Powered)

DBPA4700020200A

Wideband High Power Amplifier 0.02GHz-3GHz，50W

• Features
• Gain: 52dB typical
• Output power +47dBm typical
• Power Added Efficiency 30% typical
• Provide protection function

RFQ

Datasheet

PIN Switches

DBSR0400030350A

Reflective 0.03-3.5GHz Coaxial SP4T Switch

• Features
• Wide Band Operation 0.03-3.5GHz
• 100W High Power Cold Switching
• Low Insertion Loss and High Isolation
• Fast Switching Speed
• TTL compatible driver included

RFQ

Datasheet
